Spreader with Enhanced Gearbox and Pneumatic Wheels
This spreader combines a solid rod linkage, an enhanced gearbox and both summer and winter sliders with its standout feature: pneumatic wheels. It is an estate spreader designed for spreading fertiliser on lawns and salt on drives and other surfaces, recommended for areas of 500 m² to 3500 m², around half a football pitch.
Key Features
- Pneumatic wheels: better grip in winter plus superior handling and balance; in summer they give a more consistent flow of material through the hopper for a better finish, which makes them essential if you spread fertiliser regularly
- Solid rod linkage: a smooth on-and-off system that outlasts a wire connection and gives a better overall user experience
- Enhanced gearbox
- Summer and winter sliders
- Over 20 settings and border control
- Tested over 1000 hours of continuous use
- Large agitator to increase flow
- New hopper mould so that no material is left in the hopper
Applications
Fertiliser spreading
Well suited to spreading fertiliser across lawns in spring and summer, with the pneumatic wheels keeping material flowing evenly through the hopper.
Salt spreading and de-icing
Properties need looking after all year round, and that includes spreading salt in winter. Use this spreader to spread salt, ice melt and dry sand efficiently and accurately during icy conditions in autumn and winter on:
- Drives
- Car parks
- Private roads
- Paths
- School playgrounds
- All weather pitches
- Other icy areas
Recommended for applications on areas of 500 m² to 3500 m², or about the area of half a football pitch.
Specifications
| Load bearing capacity | 45 kg |
|---|---|
| Maximum load when in use | Do not exceed 30 kg |
| Settings | Over 20, with border control |
| Testing | Over 1000 hours of continuous use |
| Wheels | Pneumatic |
| Linkage | Solid rod |
| Sliders | Summer and winter |
| Recommended area | 500 m² to 3500 m² |
Spreader Settings (using 3 Hole Slider)
| Pass | Material | Spread Width (m) | g/m² | Setting |
|---|---|---|---|---|
| Single Pass | Micro (Granule size = 1.5mm) | 3 | 15 | 10 |
| Single Pass | Micro (Granule size = 1.5mm) | 3 | 20 | 11 |
| Single Pass | Micro (Granule size = 1.5mm) | 3 | 25 | 12 |
| Single Pass | Micro (Granule size = 1.5mm) | 3 | 30 | 13 |
| Single Pass | Micro (Granule size = 1.5mm) | 3 | 35 | 14 |
| Single Pass | Mini Granule (1-3mm) | 3.5 | 25 | 13 |
| Single Pass | Mini Granule (1-3mm) | 3.5 | 30 | 14 |
| Single Pass | Mini Granule (1-3mm) | 3.5 | 35 | 16 |
| Single Pass | Mini Granule (1-3mm) | 3.5 | 40 | 17 |
| Single Pass | Large (3mm+) | 3.8 | 35 | 14.5 |
| Single Pass | Large (3mm+) | 3.8 | 45 | 16 |
| Single Pass | Large (3mm+) | 3.8 | 55 | 17.5 |
| Single Pass | Organic moss-control fertiliser | 4 | 50 | 20 |
| Double Pass | Organic moss-control fertiliser | 4 | 75 | 20 |
| Triple Pass | Organic moss-control fertiliser | 4 | 100 | 20 |
Notes
- For successful and accurate spreading, all materials should be dry and have a consistent granule size.
- The settings in the table are a guide only. Differences in the physical properties of the material, your walking speed and how rough the ground is may mean slightly different settings are needed, so uniform coverage from the listed settings cannot be guaranteed.
